Overview
Serve commercial and enterprise businesses from one network
The Calix AXOS® E5 Ethernet Service Access Nodes integrate Carrier Ethernet 10G and 1G UNI service demarcation and Ethernet aggregation capabilities to deliver premium business and mobile backhaul services with operational efficiency and service assurance.
1Gb UNI Service
AXOS E5 Business Solutions: E5-308
The AXOS E5-308 multiservice carrier grade Ethernet Service Access Node (ESAN) and customer Ethernet demarcation device delivers MEF CE 2.0 certified services to businesses and mobile base stations. With eight GE ports and optional Power over Ethernet (POE), the AXOS E5-308 delivers a wide range of business services to many customers, enabling the fastest time to revenue.
Download data sheet
(log-in required)
10Gb and 1Gb UNI service
AXOS E5 -2 Business Solutions: E5-520
The AXOS E5-520 multiservice carrier grade Ethernet Service Access Node (ESAN) and customer Ethernet demarcation device delivers MEF CE 2.0 certified services to businesses and mobile base stations.
The E5-520 delivers IP and Carrier Ethernet Services in compliance with MEF CE 2.0 via 10G and 1G subscriber ports. With twenty GE ports, the E5-520 can deliver independent Ethernet business services for up to twenty business Ethernet subscribers, provide ring and point-to-point access network aggregation, or any combination of the two on any ports.
Download data sheet
(Log-in required)
Leverage a design specifically for the demanding business services market.
Deliver more services to more subscribers, enabling the fastest time to revenue.
Deliver Carrier Ethernet services to any location with maximum confidence.
Any service, any location
Deliver Carrier Ethernet services with confidence
- MEF Carrier Ethernet (CE) 2.0 Certified services for a global business subscriber base
- Multi-CoS and Ethernet OAM deliver differentiated services with real-time service assurance
- 10G and 1G demarcation and service aggregation from a single compact unit
- Any port, any service, any application flexibility to make network deployment easy
- Flexible Ethernet, GPON, and 10G PON network deployment options
- Embedded subscriber access security for Broadband Forum 1:1 and N:1 service models
- Environmentally hardened for deployment in a wide variety of physical locations
- Delivers "Timing as a Service" for LTE-advanced packet networks
- Integrated Power of Ethernet (PeE) to delivering data, power, and timing from one system
Product Line | Ethernet Ports | Input Power |
E5-308 DC | 4 GE SFP, 4 GE RJ-45 | 2 DC redundant |
E5-308 AC | 4 GE SFP, 4 GE RJ-45 | 2 integrated AC redundant |
E5-520 DC | 2 10GE XFP, 2 10GE SFP+, 20 GE SFP | 2 DC redundant |
E5-520 AC | 2 10GE XFP, 2 10GE SFP+, 20 GE SFP | 1 integrated AC, 1 DC redundant |
Ethernet
- 802.3 Ethernet bridging
- VLAN cross-connect
- 802.1p prioritization
- 802.1Q VLAN tagging
- 802.1ad VLAN stacking (Q-in-Q) support
- 802.1w RSTP
- 802.3ad link aggregation
- G.8032 Ethernet Ring Protection Switching
- Calix Ethernet Ring Protection Switching
Carrier Ethernet OAM
- 802.3ah Link OAM and Dying Gasp
- 802.1ag Connectivity Fault Management
- Y.1731 OAM functions and mechanisms for Ethernet based networks
- Y.1564 Ethernet service activation test methodology
- Service activation testing (SAT): generation, loopback, and analysis
Quality of service
- Traffic prioritization based on L2 802.1P and L3 DSCP
- Committed and excess information rate (CIR and EIR)
- MEF compliant single and two level hierarchical QoS
- Color blind and color aware policers
- Configurable weighted random early detection (WRED) per queue
- Scheduling options: strict priority, deficit weighted round robin, and maximum rate control
Network synchronization
- 1588v2 Precision Time Protocol
- G.826x Synchronous Ethernet
- Building Integrated Timing Supply (BITS)
Multicast management
- IGMPv2 Proxy
- IGMPv3 Proxy
Operating temperature
- DC power models: -40C to +65C
- AC power models: 0C to +50C
Specifications and features subject to change.
